| Video/Audio Input |
|---|
| Audio Input: |
|
4-ch |
| Video Compression: |
|
H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
| Analog and HD-TVI video input: |
|
8-ch,BNC interface (1.0Vp-p, 75 Ω)connection |
| Supported camera types: |
|
Support HDTVI input: 8 MP, 5 MP, 4 MP, 3 MP, 1080p30, 1080p25, 720p60, 720p50, 720p30, 720p25
Support AHD input: 5 MP, 4 MP, 1080p25, 1080p30, 720p25, 720p30
Support CVI input: 4 MP, 1080p25, 1080p30, 720p25, 720p30
Support CVBS input |
| Video Input Interface: |
|
BNC (1.0 Vp-p, 75Ω) |
| Audio Compression: |
|
G.711u |
| Audio Input Interface: |
|
4-ch, RCA (2.0 Vp-p, 1 KΩ) |
| Two-way Audio: |
|
1-ch, RCA (2.0 Vp-p, 1 KΩ), (using the 1st channel of audio input) |
| Video/Audio Output |
|---|
| CVBS Output: |
|
1-ch,BNC(1.0Vp-p,75Ω),resolution:PAL:704x576,NTSC:704x480 |
| HDMI/VGA Output: |
|
VGA: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
HDMI: 1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Frame Rate: |
|
Main stream:
Main stream:
8 MP@8fps/5 MP@12fps/4 MP@15fps/3 MP@18fps
1080p/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
Sub-stream:
WD1/4CIF/CIF@25fps (P)/30fps (N) |
| Video Bit Rate: |
|
32 Kbps-10 Mbps |
| Stream Type: |
|
Video/Video&Audio |
| Two-way Audio: |
|
1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input) |
| Audio Output: |
|
1-ch RCA(Linear, 1kΩ) |
| Audio Bit Rate: |
|
64kbps |
| Dual Stream: |
|
Support |
| Synchronous Playback: |
|
8-ch |
| Network management |
|---|
| Remote connections: |
|
64 |
| Network protocols: |
|
TCP/IP, PPPoE, DHCP, Hik-connect Cloud P2P,DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP?, HTTPS,ONVIF |
| Hard Disk Driver |
|---|
| Interface Type: |
|
2 SATA Interfaces |
| Capacity: |
|
Up to 10 TB capacity for each disk |
| External Interface |
|---|
| Network Interface: |
|
1; 10M / 100M / 1000M self-adaptive Ethernet interface |
| USB Interface: |
|
1 USB 2.0 Interface & 1 USB 3.0 Interface |
| Serial Interface: |
|
1; standard RS-485 serial interface, half-duplex |
| Alarm Input: |
|
8-ch |
| Alarm Output: |
|
4-ch |
| General |
|---|
| Power Supply: |
|
12 VDC |
| Consumption: |
|
≤ 20W(without hard disks) |
| Working Temperature: |
|
-10 oC to +55 oC (14 oF to 131 oF) |
| Working Humidity: |
|
10% to 90% |
| Dimensions: |
|
380 × 320 × 48 mm (15.0 × 12.6 × 1.9 inch) |
| Weight: |
|
≤ 1.78 kg (3.9 lb) |
|
