SINGLE PORT POE MIDSPAN LAS60-57CN-RJ45
New product
Hikvision POE midspan is designed to extract power from a conventional twisted pair Category 5 Ethernet cable, conforming to the IEEE 802.3at Power-over-Ethernet (PoE) standard. The converter signature and control circuit provides the PoE compatibility signature and power classification required by the Power Sourcing Equipment (PSE) before applying up to 60W power to the port
More info
Model LAS60-57CN-RJ45
Input Current 2A
Output Voltage Range 54V~57V
Output Power 60W
Pass Through Data Rates 10/100/1000 Mbps
Ports Two 10/100/1000M adaptive RJ45 ports, one is DATA/IN, another is PoE/DATA
LED Indicator Power & PoE Status(The module operates normally when MID and END are on)
Base Function Compliance to IEEE 802.3 at/af Standard for PD
Network Medium 10BASE-T: unshielded twisted pair category 3, 4 or 5 100BASE-TX: unshielded twisted pair category 5 and above 1000BAST-TX: unshielded twisted pair category 5 and above
Protection Methods Output Over Current Protection, Short Circuit Protection
